D24100 Datasheet
Download
| Stored energy | 2560Wh | |
| Rated capacity | 100Ah | |
| Nominal voltage | 25.6V | |
| Volt range | 20V-28.8V | |
| Charge time | Standard | 5.5h |
| Rapid | 1.5h | |
| Charge method CC-CV | Standard | 20A/28V |
| Rapid | 100A/28V | |
| Max discharge continous current | 100A | |
| Cycle life 0.5C, 23℃/73°F | 50% | ＞7000 cycles |
| 100% | ＞2000 cycles | |
| Operating temperature range | Charge | 0°C~55°C/32°F~131°F |
| Discharge | -20°C~60°C/-4°F~140°F | |
| Storage(1month) | -20°C~45°C/-4°F~113°F | |
| Storage(6month) | -10°C~35°C/14°F~95°F | |
| Water proof | IP66 | |
| Approx weight | 22kg /48.5lbs | |
| Series & parallel connection | -Maximum 2 in series connection. -Supports multiple batteries in parallel for yacht and RV applications. -Batteries must be fully charged before connecting in series or parallel. | |
| Length | Width | Width |
| 502mm | 187mm | 241mm |
| 19.76in | 7.36in | 9.49in |
| Balance | Current | 40mA |
| Activate volt | 3.3V/ cell | |
| Cell Voltage difference | ≥30mV | |
| High temperature protection(MOSFET) | Protection | 105°C/221°F |
| Release | 85°C/185°F | |
| High temperature protection(cell) | Protection | 65°C/149°F(charge) |
| 75°C/167°F(discharge) | ||
| Release | 55°C/131°F(charge) | |
| 65°C/149°F(discharge) | ||
| Low temperature protection(cell) | Protection | -10°C/14°F(charge) |
| -20°C/-4°F(discharge) | ||
| Release | -5°C/41°F(charge) | |
| -10°C/14°F(discharge) | ||
| Over-charge | Protection | 30V(3.75V/cell) |
| Release | 28.4V(3.55V/cell) | |
| Over-discharge | Protection | 18.8V(2.35V/cell) |
| Release | 19.6V(2.45V/cell) | |
| Short-circuit | Protection | 1000A |
| Release | Remove load for the short circuit protection to release |
| Length | Width | Width |
| 502mm | 187mm | 241mm |
| 19.76in | 7.36in | 9.49in |
Marine Energy Storage: Reliable power for onboard living and entertainment. Ensures worry-free daily life and leisure on vessels.
Marine Propulsion: Outperforms lead-acid batteries – complete 2 more trips. Delivers extended range and higher efficiency for marine engines.
RV Energy Storage: Compact size, massive energy – say goodbye to power worries. Perfect for campers and mobile homes with stable, long-lasting power.
Fishing & Leisure: 3X longer runtime – catch more fish with confidence. Maximizes fishing time with uninterrupted power supply.
Forklift & Logistics: Heavy-duty outdoor operations – enhanced endurance, boosted productivity. Ideal for industrial vehicles and fieldwork with superior stamina.
Home & Agricultural Use: Indoor/outdoor versatility, waterproof & durable – no more power outages. Reliable backup power for farms, households, and emergency scenarios.
Starts–Automatically activates heating at ≤0°C and stops at 15°C for reliable performance in extreme cold.
Universal Compatibility–Supports 12V/24V/48V marine power systems, adaptable to all vessel types.
3x higher energy density than lead-acid batteries.
100% Depth of Discharge (DOD).
Fully compatible with lead-acid battery chargers.
Built-in high-precision BMS.
Bluetooth connection for real-time voltage/current/temperature display.
Supports remote monitoring via APP (iOS/Android).
IP67 waterproof & dustproof rating.
Corrosion and oxidation resistant design.
Adapts to various harsh environments.
2000+ cycles at 100% DOD.
5x longer lifespan than lead-acid.
More economical long-term use.
Operating range: -20℃ to 60℃.
Real-time temperature monitoring.
Stable year-round operation.
Only 1/3 the weight and volume of lead-acid.
50% longer runtime compared to lead-acid, with no RC degradation after 1,000 cycles.
Saves space and transportation costs.
Tailored options for different scenarios, flexible pricing to suit all budgets.
Fast delivery, worry-free after-sales service—effortless and reliable.
