ESS-05 Datasheet
Download
CANBUS/RS485/RS232 protocol compatible
| Stored energy | 5.120kWh |
| Rated capacity | 100Ah |
| Nominal voltage | 51.2V |
| Volt range | 43.2V-57.6V |
| Charge time | Standard2.2h |
| Rapid1.5h | |
| Charge method CC-CV | Standard50A/56V |
| Rapid100A/56V | |
| Surge(10S) 120A(10S) | |
| Max discharge current | Continous 100A |
| Cycle life 0.5C, 23℃/73°F | 80% ＞7000 cycles |
| Operating temperature range | Charge 0°C~60°C/32°F~140°F |
| Discharge -20°C~60°C/-4°F~140°F | |
| Storage(1month) -20°C~45°C/-4°F~113°F | |
| Storage(6month) 0°C~35°C/32°F~95°F | |
| Communication port | RS232/RS485/CAN |
| Approx weight | 52kg /115lbs |
| Series & parallel connection | Max 16 batteriesin parallel connection.Series connection is not available. |
| Length | Width | Width |
| 390mm | 160mm | 690mm |
| 15in | 6.3in | 27.2in |
| Balance | Current | 30mA |
| Activate volt | ＞3.55V/ cell &cell Voltage difference＞30mV | |
| High temperature protection(MOSFET) | Protection | 115°C/239°F |
| Alarm | 90℃/194℉ | |
| Release | 85°C/185°F | |
| High temperature protection(cell) | Protection | 65°C/149°F(charge) |
| 70°C/158°F(discharge) | ||
| Alarm | 60°C/140°F(charge) | |
| 65°C/149°F(discharge) | ||
| Release | 55°C/131°F(charge) | |
| 60°C/140°F(discharge) | ||
| Low temperature protection(cell) | Protection | 0°C/32°F(charge) |
| -20°C/-4°F(discharge) | ||
| Alarm | 5°C/41°F(charge) | |
| -15°C/5°F(charge) | ||
| Release | 5°C/41°F(charge) | |
| -15°C/5°F(discharge) | ||
| Heating (option) | Activate | Temp≤5°C &Charge current≥4A |
| Release | Temp＞15°C &Charge current ＜4A | |
| Over-charge | Protection | 59.2V(3.7V/cell) |
| Alarm | 57.6V(3.6V/cell) | |
| Release | 54.08V(3.38V/cell) or SOC＜96% | |
| Over-discharge | Protection | 43.2V(2.7V/cell) |
| Alarm | 44.8V(2.8V/cell) | |
| Release | 47.2V(2.95V/cell) or charge the battery | |
| Primary over- current | Protection | 130A(1S) |
| Alarm | 125A | |
| Release | Automatic release after 60S | |
Secondary over-current | Protection | 180A(0.5S) |
| Release | Automatic release after 60S | |
| Short-circuit | Protection | Yes |
| Release | Remove load or charge the battery | |
| Lose Efficacy | Activate | cell Voltage difference＞1V (battery can't charge & discharge ) |
| BMS record | Capacity | ≥1000 records |
| Length | Width | Width |
| 390mm | 160mm | 690mm |
| 15in | 6.3in | 27.2in |
Check battery status and power usage remotely via smartphone or computer, keeping you in control no matter where you are.
Equipped with a built-in 5KVA inverter and 48V energy storage battery, eliminating the hassle of traditional inverter setup, battery wiring, and complex assembly—truly "ready to use out of the box."
Features an intelligent BMS that automatically assigns IP addresses and networks connected batteries. If voltage difference exceeds 1.5V, the system isolates charge/discharge circuits to prevent cross-charging and extend battery life.
The BMS communicates with the inverter in real-time, dynamically monitoring charge levels, temperature, and other parameters to intelligently adjust voltage and current—preventing overcharging and overheating risks.
Built-in heating system activates when temperatures drop below 0°C and charging current exceeds 5A, warming the battery to 20°C for stable charging and discharging even in harsh winter conditions.
